SKU: CLK-SK680A
SK-680A Full-Automatic Non-Mydriatic Fundus Camera
SK-680A fully automatic non-mydriatic fundus camera. Features 10MP 1-inch CMOS sensor, switchable 30/45 FOV, automatic alignment & focus, 10.1" rotating touchscreen, DICOM 3.0, AI-powered mosaic stitching, and optional FA/ICG fluorescence. Designed for diabetic retinopathy screening, retinal documentation, glaucoma assessment, and anterior-segment imaging.
MOQ
1 Unit
Origin
China
Product Overview
Key Features
- Fully automatic: alignment, focus, and one-touch capture
- Non-mydriatic design — minimum pupil size 3.3 mm
- 1-inch CMOS sensor, 10 MP (up to 24.1 MP in some configurations)
- Switchable field of view: 30 / 45 (up to 53 in some versions)
- Anterior & posterior segment imaging modes
- 10.1" rotating capacitive touchscreen (270° rotation)
- 9-11 internal fixation points for peripheral imaging
- Automatic image mosaic / seamless stitching
- DICOM 3.0 network connectivity for PACS/HIS integration
- Patient database, measurement tools, PDF report generation
- Comfort flash & soft-lighting technology
- Optional FA/ICG fluorescence angiography (configuration-dependent)
Clinical Applications
- Diabetic retinopathy screening
- Retinal photography & documentation
- Optic-disc & macular imaging
- Glaucoma assessment support
- Hypertensive retinopathy evaluation
- Age-related macular degeneration monitoring
- Peripheral retinal imaging via fixation targets
- Anterior-segment documentation (cornea, iris, lens)
- Fluorescein angiography (FA) & ICG angiography (if configured)
- Tele-ophthalmology & remote consultation
- Medical education & research
Workflow Advantages
- One-touch operation reduces training needs & examination time
- Small-pupil imaging (3.3 mm) without mandatory dilation
- Automatic alignment, focus & flash intensity
- Seamless mosaic stitching for wide-field views
- Auto report generation in PDF format
- DICOM 3.0 ready for hospital PACS/HIS integration
- Rotating touchscreen for ergonomic positioning
- Standalone with embedded system or upper-computer configuration
Technical Specifications
Product Model
SK-680A
Brand
Sun Kingdom
Manufacturer
Chongqing Sunkingdom Medical Instrument Co., Ltd.
Device Type
Full-Automatic Non-Mydriatic Fundus Camera
Imaging Type
Full-automatic color fundus photography
Sensor
1-inch CMOS, 10 MP (up to 24.1 MP in SLR configurations)
Field of View
30 / 45 (up to 53 in some configurations)
Minimum Pupil Size
3.3 mm (non-mydriatic)
Focus Method
Optical split-line focusing; auto/manual
Alignment
Automatic alignment and positioning
Capture Mode
Automatic and manual
Anterior Segment
Supported (switchable lens mode)
Posterior Segment
Standard fundus imaging
Fluorescence Imaging
FA/ICG available on some configurations — confirm exact model
Fixation Targets
9-11 internal fixation points
Display
10.1-inch touchscreen, 270° rotation, 1440×900 resolution
Working Distance
Approximately 40-42 mm ±2 mm
Diopter Compensation
Approximately 15D to 23D (configuration-dependent)
Light Source
Infrared LED for alignment; visible flash for capture
Optical Resolution
Center 60 lp/mm (FOV >30°); Edge 25 lp/mm
Network
DICOM 3.0; LAN/Ethernet
Power Supply
100-240 V AC, 50/60 Hz
